Hydraulic Cylinder |
Max working pressure | 16 MPa |
System pressure | 380 V |
System flow | 38 L/min |
Individual maximum displacement | 5 L/min |
Tank capacity | 300 L |
Motor speed | 1470 r/min |
Control voltage | DC 220 V |
System temperature | 20-60ºC |
Size | 2500*2000*1500 mm |
Advantages of inverted hydraulic pressure in improving large
construction storage tanks.
1. The hydraulic lifting is stable, safe and reliable. Due to the
use of unified hydraulic control and single or partial (several)
adjustment, the entire lifting process is relatively stable. The
hydraulic top is equipped with a synchronous valve and a hydraulic
lock to prevent the oil tank from slipping or heavy loading due to
power failure, tubing breakage. Hydraulic lifting is stable, safe
and reliable.
2. Ensure construction quality. The hydraulic top has synchronizer
and adjustable function, which can accurately control the lifting
height. For the above reasons, the quality of the copter is
guaranteed.
3. The device is easy to operate. The construction environment is
good and the work efficiency is high.
4. The equipment ADAPTS well. As long as the number of hydraulic
tops is increased or reduced, the whole set of equipment can be
applied to the construction of flip tanks with thousands of cubic
meters of different volumes of large storage tanks.
5. The hydraulic pump station and hydraulic top are placed in the
tank for easy operation. Finally, a closed door plate is reserved
for moving the equipment out of the storage tank, and the closed
door plate is welded.
6. Hydraulic pump station can be controlled individually or
jointly, with strong construction adaptability and excellent
technical performance/price ratio.
7. Short construction period, low cost, good economic benefits. Due
to the high degree of modernization, the upgrading speed of
complete sets of equipment is fast, the construction cost is low,
and the economic benefits are good. The technology has the
characteristics of convenient and centralized control, simple
operation, safe and reliable (no fall), accurate control of weld
gap and lifting height of heavy objects, etc., which can ensure
project quality, save labor, reduce costs, and achieve significant
economic benefits.
